Customized Warehouse Drive In Racking System , High Density Pallet Racking System

Model NO. : QF-Drive in Rack

Material : Steel

Structure : Rack

Type : Pallet Racking

Mobility : Fixed

Height : 5-15m

Weight : 2000

Closed : Open

Development : New Type

Serviceability : Common Use

Color : Customized

Lead Time : 25 Days

Raw Material : Q235

Surface Treatment : Powder Coating

Transport Package : Standard Export Packing

Specification : 1200*1200*3600

Trademark : Customized

Origin : China

HS Code : 730890

Supply Ability : 50000PCS/Year

Package Size : 1000.00cm * 1000.00cm * 1000.00cm

Package Gross Weight : 100.000kg

After-sales Service : Available

Warranty : 1 Year

Usage : Tool Rack, Beverage, Clothing, Tools, Supermarket, Food, Industrial, Warehouse Rack

Samples : US$ 60/Piece 1 Piece(Min.Order) |

Customization : Available | Customized Request

Shipping Cost : about shipping cost and estimated delivery time.

: Initial Payment Full Payment

Currency : US$

Return&refunds : You can apply for a refund up to 30 days after receipt of the products.

Contact Now

Sturdy Customized Drive in Rack Shelf for Warehouse Storage Durable and Customizable

QiFei Drive-in rack:

Drive-in rack is a high-density and very space-efficient type. Drive In or Double Access Systems (Drive-through Racking) consists of continuous lanes of racking with only a single load and retrieval aisle. Loading and unloading is undertaken by means of counter balance or reach trucks that drive down each lane into the racks.
Customized Warehouse Drive In Racking System , High Density Pallet Racking System

Customized Warehouse Drive In Racking System , High Density Pallet Racking System

Dimensions	standard pallet size 1200x1000 / 1200x1200 / 1100x1100 / 1200x800mm
Loading	2000KG per pallet(max)
Stacking levels	4 beam levels
Thickness section	upright 8868 / 10068mm; beam 80~100*45
Colour	Blue, orange, Yellow and Grey or customized
Custom design	Accpeted
Surface treatment	Galvanized/Powder Coating
Quality&Services	1. Free customized design 2. Installation Instructions provided. 3. Quality cerfiticate at least 5 years. 4. We will deliver back-up accessories for maintenance along the container.

RFQs for drive in rack:

1, Under which situation should we use drive in pallet rack?

For inventory with less categories and large quantities for eack category.

2, How many depth do you plan along each drive in aisle?

For single entry, we suggest no more than 7.
For double entry, we suggest no more than 13.

3, what kind of pallet can we use in drive in pallet rack?

pallets with double faced, pallets with three runners base.
Single faced, 9 feet or any plate based will be prohibited.

4, How about the installation?

It will take 5-6 persons to do installation.
We have installation drawing for you to follow,it will be easy to carry out project installation if you follow our instruction.

5, How long do we need to wait for your production?

20 days before shipment.

6, What is your MOQ?

50pallets

Placing a pallet

1. Driver should square the forklift with the pallet rack bay opening.
2. Lift the pallet 20mm above the rails.
3. Slowly drive to the open pallet position and carefully lower the pallet.
4. Slowly back away from the system.

Retrieving a pallet

1. Square the forklift outriggers elevated to the height of the pallet to be removed.
2. Secure the pallet with the forklift.
3. Raise the load approximately 20 mm above the rails and slowly and completely out of the system.
4. Carefully turn the forklift in the aisle to prevent rack impact and damage.

APPROACHING AND ENTERING THE RACK

1. The forklift truck should approach the rack squarely and not at an angle.
2. No attempt should be made to deposit/retrieve pallets or to enter a rack when the truck is NOT ncorrectly aligned.
3. lt is not acceptable to attempt to re-align a truck after entry into the rack.

Customer Site

Customized Warehouse Drive In Racking System , High Density Pallet Racking System

Packing
Customized Warehouse Drive In Racking System , High Density Pallet Racking System Shipping

Welcome to visit our company

Customized Warehouse Drive In Racking System , High Density Pallet Racking System

Q: Are you manufacturer or trading company?
A: We are experienced manufacturer in the warehouse storage industry.

Q: How is your delivery time?
A: Generally, it is within 20 days against formal order and deposit. It also depends on other factors such as order quantity.

Q: What is the payment term?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.

Q: What is your terms of delivery?
A: EXW, FOB

Q: Are samples available?
A: Yes, We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

Q: What is the minimum order quantity?
A: Generally, MOQ is 10sets.

Q: Can I make my own brand and designed products?
A: Yes, we do both OEM and ODM, so you can make your own product with your own logo.

Q: Where is your factory? Can I visit it?
A: Our factory located in Nanjing, Welcome to visit our factory. We can arrange pick-up from the airport or train station for you.

Q: What is the material being used for your products?
A: Mild steel Q235.

Q: I don't have drawing or picture available for the products, could you design it for me?
A: Yes, we can make the best suitable design for you but need to know more details.

Q: Do I get any guarantee from your company?
A: 3 years warranty

Q: How do you make our business long-term and good relationship?
A: Quality makes trust and reputation, plus competitive price to ensure our customers benefit ;
